DPA5 Dearborn Protocol Adapter 5 Heavy Duty Truck Diesel Diagnostic Tool DPA 5

Note: This item does not include Bluetooth Function

Dearborn Protocol Adapter 5 Description:

Dearborn Protocol Adapter 5 is designed to help manufacturers diagnostic the fault of trucks,trailers, buses and light commercial vehicles. It covers multiple systems and widely used, it's user friendly.Dearborn Protocol Adapter 5 is an proferssinal tool for the maintenance of the commercial vehicle manufacturers.It covering all critical systems, including engines, transmissions, brake warning device, comfort, safety, emissions, air suspension, trailer and maintenance, to provide in-depth functionality for each application. It is based on the DS tool technology,it can use for the following hardware platforms: PC, Pocket PC (PDA) or netbook (UMPC,also known as Ultra Mobile PC),and provide information update for customers by regularly upgraded the supporting software.

FREE Heavy-Duty Truck Diagnostic Applications

1, For for VOLVO TRUCK: FM10, NH565, FH12, FM12, VHD, FH16, FM7, VN, WC, WG, WI, FH565, NH12, FL6, FL7, FL10, FL12, NH525, WX, COMP04, FE, VHD, FH, FM, VM, FM9, F10, F12 , F16, NL10, NL12,for VOLVO BUSES: B10B, B10M, B10L, B10R, M10R, B12, B58, B6, B7R, OLYMPIAN, SUPEROLY

2, for VOLVO BUS: B12B, B12M, B12R, B6R, B7L, B7R, B9L, B9R, B9S, B9TL, PREVH, PREVX

3, for MACK TRUCKS: V-MAC I, V-MAC II, V-MAC III, V-MAC IV, Service Diagnostic

4, for VOLVO CONSTRUCTION EQUIPMENT (CE):

* Wheel loader: L110E, L110F, L120E, L120F, L150E, L150F, L180E, L180F, L220E, L220F, L330E, L350F, L60E, L60F, L70E, L70F, L90E, L90F

* Articulated Hauler: A25D, A25E, A30D, A30E, A35D, A35E, A40D, A40E, T450D

* Excavator: EC135B, EC140B, EC140C, EC160B, EC160C, EC180B, EC180C, EC210B, EC210C, EC235C, EC240B, EC240C, EC290B, EC290C, EC330B, EC330C, EC360B, EC360C, EC460B, EC460C, EC700C, EC700B, EC700C, ECR145C, ECR235C, ECR305C, EW140B, EW140C, EW145B, EW145C, EW160B, EW160C, EW180B, EW180C, EW200B, EW210C, FC2121C, FC2421C, FC2924C, FC3329C, PL4611

* Grader: G710B, G720B, G726B, G730B, G740B, G746B, G780B, G930, G940, G946, G960 , G970, G976, G990

5, Navistar: ALL Diamond Logic Builder (DLB) ServiceMaxx

6, International: ALL Intune, MD32

7, for Freightliner: ALL

ServiceLink: cascadia, century, columbia, Coronado, classic, FLDSD, 4900FA, 4900SA, 4900EX.

engineS

1, Detroit Diesel Diagnostic Link (DDDL)

All DDEC VI equipped engines

DD13,DD15,DD16,SERIES60,MBE4000,MBE900,and RS9, RSX9-A,RSX9-B, RSX9-R, RS10, RSX10 J1939 engine brake level for Series 2000 and 4000 Engines with USA and ISO firing order selection

2, Caterpillar (on high way engine for j1939)

3126, 3406, 3306B, 3512C, C4.4, C6.6 C7 C9 C11, C13

3, for Cummins INSITE7.6 insite7.5

Transmissions Brakes

1,Meritor WABCO toolbox

D and E Versions ,HABS, hpb, ESC, RSC, ECAS

2,Bendix® ACom™ Diagnostics

EC-17T, Generation 4 and 5, EC-30T, EC-60T (standard, premium and advanced), A-18T,MC-30T and the trailer antilock braking TABS-6 unit

3, Meritor ZF

4,Eaton Service Ranger

Vorad VS-400 Collision Warning System

Generation 2 Auto shift and Ultra shift Transmissions

Generation 3 Auto shift and Ultra shift Transmissions

Ultra Shift PLUS Transmissions

Lightning Transmissions

Hybrid Drivetrain Systems

5,Allison DOC

Allison1000,2000,3000,4000,

Cec2-5610,6610,8610,9610

CEC-MTB600,CLBT-V,HT700,B700

CEC-5,CEC-6,CEC-8,CEC9000

Support more software update !!!

PC-to-Vehicle Interfaces

API Support:

• RP1210A/B

J2534-2

• supports Windows xp and windows 7 32-bit and 64-bit and windows CE compliant

Not all applications are included. If compatibility confirmation is required, more information is needed, or there are questions about an unlisted application, please contact your dealer,he will send E-mail to us,. A specialist will help you make the right choice.

Protocol Coverage:

CAN - J1939/CAN125/CAN250/CAN500/CAN1000

2nd CAN - J1939/CAN125/CAN250/CAN500/CAN1000

J1587/J1708 J1850 J2534

ISO 15765 (Diagnostic CAN)

ISO 14230 (KWP2000 over ISO9141) ALDL ATEC 160 (160 baud)

Software Interface Capability(Includes DVD)

Detroit Diesel Diagnostic Link 7.05

Caterpillar Electronic Technician 2010B

for Cummins Insite 7.5 (windows XP and 7), inste 7.6 (only for windows 7)

International - ServiceMAXX Fleet Pro

for VOLVO PTT 2.40

VCADS /Elite Mack/for VOLVO 2.35

V-MAC Service Tools

Allison DOC For PC-Service Tool - Protocols Supported: J1939,for GMLAN, J1708/J1587, J1850, and

ATEC160

Allison DOC For PC (AED) - Protocols Supported: J1939

Allison DOC For Fleets (1000/2000) - Protocols Supported: J1939, J1850, for GMLAN

Allison DOC For Fleets (3000/4000) - Protocols Supported: J1939, J1708/J1587

Eaton ServiceRanger 3.2

Bendix Acom

ZF-Meritor TransSoft / WABCO Toolbox

International ABS

International DLB

International Intune

International IPC v2.02

Perkins EST Diagnostic Interface 2010

Note:

1, Above all software has keygen or crack files in DVD

2, Next we will supply freely software of New Holland and Others

J2534 OEM Software (Does Not Include Software)

The adapter you have purchased is provided with an SAE J2534-compliant interface (an SAE standard for electronic module reprogramming). The DPA5 should be able to reprogram all CAN/ISO15765 vehicles, for G-M vehicles using the J1850 Variable Pulse Width (VPW) protocol, or other vehicles using the DPA5 J2534-supported protocols (i.e. ISO9141/KWP2000).

The DPA5 has been validated against the following OEM and component applications:

for Cummins PowerSpec

for Freightliner ServiceLink

Vansco VMMS

Dana Diagnostic Tool

Mitchell1 RepairConnect

for General M-otors TIS2Web

For Ford Module Programming (FMP)

For Chrysler J2534 Application

For Toyota TIS (Technical Information System)

For Honda Service Express

For Mazda Module Programming (MMP)

For Kia J2534 KMA

For Hyundai 2534 HMA

For Volkswagen Erwin

For Audi Erwin

For Nissan J2534 ECU Reprogramming Software (NERS)

All J2534 reprogramming and diagnostic software packages that are J2534-1 and J2534-2 compliant and use a protocol supported by the DPA5 should work as long as the operating system is supported by the application. Note that not all OEMs have released J2534-2 compliant software.

Packing-list

Cables and Accessories (Kit)

Kit Includes (6 Cable);

1X DG-DPA5-YDUALCAN

1X DG-DPA5-9OBDII_for VOLVO

1X DG-DPA5-for VOLVO8PIN

1X DG-DPA5-for VOLVO14PIN

1X DG-DPA5 KOMATSU

1X DG-DPA5-3Pin_Deutsch

1X DG-OBDii-o-Cable

1X DG-DPA5-15USB
